PDA Testing will provide prediction on the pile bearing capacity, pile integrity, driving stresses and hammer performance for a given pile penetration. It is a relative low cost type of pile testing compared to static load test (MLT or CRP). The testing technique is quick and accurate.PDA also can be used to perform high strain pile bearing monitoring to evaluate pile driving information for pile bearing capacity, pile integrity, driving stresses and transferred energy against pile penetration. The results are essential for the actual pile driving process and to obtain valuable data on the hammer, pile & soil system for re-design on the piled foundation(if necessary).
YPDT:
Product Features
u 8.4" true-color high-brightness touch screen with continuously adjustable backlight, clear display of data and curves, adaptable to various environments
u Ergonomic design with high-strength aluminum alloy structure, light weight, small size, ease for long-time working
u Real-time monitoring of on-site sensor installation status, compatible with mainstream connectors and sensors on the market
u Professional wizard design, optimized detection procedure, simple operation for efficient testing
u Automatically realizes continuous acquisition, superposition, and balance adjustment; high precision in time domain and frequency domain analysis
u Large AD dynamic range and high signal-to-noise ratio; adaptive floating-point amplification without distortion
u Accurate data collection, automatic strain balance adjustment to eliminate signal drift
u Fast sampling, supporting real-time collecting and monitoring with a speed of over 60 strikes/minute
u On-site instant results of the CASE analysis including speed, force curve, bearing capacity and impact force
u Optimized the simulation on-site process, instantly identify defects for easy integrity judgment
Software Features
u Provides CASE analysis, matching analysis and various quick settings
u Supports automatic analysis, manual result correction and intervention
u Provides a variety of reference soil models close to the geological characteristics
u Supports original signal processing, including digital filtering, fixed pile length, fixed wave speed, waveform moving
u Supports quick view of the analysis results and switching to compare with historical results
Provides multiple output formats such as .docx/.doc and .bmp
No. | Item | Quantity | Remark |
1 | YLPDT | 1 | / |
2 | High strain accelerometer | 2 | High precision |
3 | High strain transducer | 2 | / |
4 | Communication cable | 1 | 20m |
5 | Communication adapter cable | 1 | / |
6 | MPC multi-function data cable | 1 | Charging and data transferring |
7 | USB flash disk | 1 | 8G |
8 | Touch pen | 1 | / |
9 | Charger | 1 | 12.6V/3A |
10 | Strap | 1 | / |
11 | Instrument box | 2 | / |
12 | Accessory box | 1 | / |
Optional | Accelerometer | 1 | / |
Optional | Special hand hammer | 1 | Including 2 nylon heads, 1 copper head |
Optional | Matching software | 1 | With dongle |
Specifications
Model | YLPDT |
Main control unit | Low power embedded industrial computer |
Display screen | 8.4" true-color LCD display screen (high-brightness) 800x600 |
Storage | 8G |
Power supply | Built-in high-performance rechargeable lithium battery, ≥6 hours |
Power display accuracy | 10% |
Operation method | Touch screen |
Sampling interval | 5μs ~ 65535μs |
Record length | 1024 dots |
Sample resolution | 24-bit AD |
Signal bandwidth | 1Hz ~ 12KHz |
Floating-point amplifier | ×1~×256 (automatically adjusted according to signal strength, 8-bit floating point) |
System noise | <20μv (accelerometer),<2μv(strain transducer) |
Dynamic Range | ≥100dB |
Data transmission mode | USB |
Number of channels | 5 channels (2 channels acceleration + 2 channels strain, 1 channel with low strain) |
Sensor | Speedometer, front IC piezoelectric accelerometer, strain transducer |
Working temperature | -20℃~+55℃ |
Dimension | 266mm × 180mm × 50mm |
Weight | 1.9 kg |
